End-Suction Centrifugal Pumps, Parts & Repairs
Corrosion Fluid Products Corp. proudly carries a wide variety of industrial, chemical-resistant, centrifugal and positive displacement (PD) pumps and pump parts from the world's best manufacturers. We supply and service pumps in Michigan (MI), Ohio (OH), Illinois (IL), Indiana (IN), Pennsylvania (PA), Iowa (IA), Kentucky (KY), West Virginia (WV), Tennessee (TN) and surrounding states.
Our large local inventory of pumps and pump parts means
quick delivery when you need it most!
Flowserve Durco Mark 3 ANSI, End Suction Pumps
Flowserve's Durco Mark 3 ANSI, end suction process pumps maximize performance and mean time between planned maintenance (MTBPM). The Micrometer Style Impeller Adjustment allows fast and accurate setting of impeller clearance without shims, jackbolts or feeler gauges. Other features include SealSentry™ FM Seal Chambers and a Reverse Vane Impeller.
Features:
- Open impeller option
- Offered in a wide range of metallurgy
- Reverse Vane Impeller
- Low, predictable seal chamber pressures
- Low required NPSH
- Rear cover wear surface
- In-shop impeller adjustment
- Repeatable performance assurance
- ANSI 3A Power End
- Certified clean room assembly
- Inpro/Seal's VBX isolators
- Magnetic drain plug
- Synthetic oil bath, oil mist, shielded, grease-lube
- Other configurations
- Mark 3 Lo-Flo
- Mark 3 Sealmatic
- Mark 3 Unitized Self-Priming
- Mark 3 Recessed Impeller
- Mark 3 In-Line
- Operating parameters
- Flows to 1680 m3/h (7400 gpm)
- Heads to 215 m (700 ft)
- Pressures to 27 bar (400 psi)
- Temperatures from -75°C (-100°F) to 370°C (700°F)
More Info on Flowserve Durco Mark 3 ANSI, End Suction Pumps
Availability: MI, IL, OH, PA
CFPC is a Top 5 Authorized Flowserve Pumps Distributor
Flowserve D800 Series Cast Iron, End Suction Pumps
The D-800 line of cast iron, end suction pumps is designed to pump water and a variety of other fluids including solvents, light oils, non-corrosive chemicals, coolants and brines. Applications include Agriculture, Brine, Coolants, Water Supply, Light Oils, Offsites, and Solvents.
Configuration options:
- Type D-814 - Frame mounted
- Type D-824 - Close-coupled
- Type D-834 - Vertical in-line
More Info on Flowserve D800 Series Cast Iron, End Suction Pumps
Availability: MI, IL, OH, PA
CFPC is a Top 5 Authorized Flowserve Pumps Distributor
Flowserve MEN Single Stage, End Suction, Water Pumps
Flowserve's MEN single stage, end suction water pump provides reliable operation in a wide variety of applications- General Purpose, Irrigation, Fire Protection, Drainage, Water Supply, Agriculture, Fountains, HVAC, Water Treatment, Circulating Water and more.
Features include Oversized stainless steel shaft, open seal chamber with integral vortex breaking ribs, back pull-out design and stainless steel studs and nuts.
Configuration options:
- MEN frame-mounted standard water pump
- MENBLOC close-coupled standard water pump
- MEN-SP cantilever sump pump
- MEN-TI diesel-driven fire pump
More Info on Flowserve MEN Single Stage, End Suction, Water Pumps
Availability: MI, IL, OH, PA
CFPC is a Top 5 Authorized Flowserve Pumps Distributor
Flowserve FRBH End Suction, Heavy-Duty Paper Stock Pumps
Overhung, Horizontal, Centerline Mounted
A rugged proven performer in demanding pulp and paper mill applications, the FRBH is an overhung, horizontal, end suction, top centerline discharge design. With 19 sizes available, the high efficiency of the FRBH means reduced operating costs. Applications include Cellulose Fiber Slurries, Condensate, Concentrator, Evaporators, Flash Tanks, Pulp and Paper, Slurries, and Waste Stock.
Features:
- Three-point end clearance adjustment
- Back pull-out design
- Heavy-duty, oil-lubricated bearings standard
- Fully split interlocking glands
More Info on Flowserve FRBH End Suction, Heavy-Duty Paper Stock Pumps
Availability: MI, IL, OH, PA
CFPC is a Top 5 Authorized Flowserve Pumps Distributor
Flowserve SMP- End Suction, Standard Motor Pumps
Overhung, Close Coupled
Flowserve's SMP standard motor pump is an overhung, end suction, close coupled, tangential discharge, frame mounted design, engineered for general industry use. Applications include Chillers, General Purpose, Water Supply, Water Treatment, HVAC, and OEM.
More Info on Flowserve SMP- End Suction, Standard Motor Pumps
Availability: MI, IL, OH, PA
CFPC is a Top 5 Authorized Flowserve Pumps Distributor
Flowserve VSMP Vertical Standard Motor Pumps
Overhung, Vertical Cantilever, Immersion Pumps
Flowserve's VSMP vertical standard motor pump is a vertical immersion centrifugal pump designed for general industry use. Applications include General Purpose, Water Supply, Water Treatment, and Sump Service. True Cantilever Design eliminates the need for shaft bushing and helps ensure a long, trouble-free life. Vertical Immersion Design requires no mechanical seal and therefore can safely pump dirty fluids. This design also is self-priming which eliminates the need for check valves or venting at start-up.
Features:
- Clamp-type mounting plate
- Self-priming
Operating Parameters
- Flows to 135 m3/h (600 gpm)
- Heads to 70 m (220 ft)
- Pressures to 12 bar (175 psi)
- Temperatures from -40°C (-40°F) to 120°C (250°F)
More Info on Flowserve VSMP- End Suction, Vertical Standard Motor Pumps
Availability: MI, IL, OH, PA
CFPC is a Top 5 Authorized Flowserve Pumps Distributor
