Briquette Press – Eco Series

ER20T Briquetter

Our Eco series of hydraulic briquetting press help reduce chip and scrap volume, recycle coolant fluids and add value to your machining wastes. As a space saving solution, chips are collected directly under conveyors or centralized in a treatment area. Chips and fines enter the press and are compacted under high pressure to form solid briquettes. Residual oil is separated out for reuse. Compacted scrap is more valuable, easier to store and ready to reuse.  Contact us for more details.

Advantages:

  • Space saving
  • Robust and simple construction
  • Feed screw with hydraulic drive
  • Recovery of cutting oil and coolant fluids for recycling
  • Rapid return on investment
  • Reasonable purchase price

Transforming chips into highly compact briquettes opens opportunity to higher value recycling. Two models available for  volume reduction providing easier transportation and storage. Direct use of scrap metal for primary or secondary fusion with re-melting or refiners. Avoid risks associated with handling of chip bins. Space saving solutions

  • Ensure quality of treated waste for a better value with control and traceability.
  • Transformation of machining sludges in briquettes directly usable in steelworks…
  • Equipped with Seimens automation
  • Premium and eco-range options fit a variety of applications
  • Can be used on a variety of ferrous or non-ferrous metals.
  • Built to handle metals in the form of chips, sludges, or dust

Two Models to choose from:

ER20T

  • Briquette Ø56mm
  • Briquetting capacity between 15 and 20Kg/h for aluminum and between 30 and 50Kg/h for steel
  • Briquetting pressure of 260 bar so 780Kg/cm²
  • Engine power 3KW
  • Hydraulic tank 45L
  • Machine dimension:
    – l = 1200mm
    – L = 840mm
    – H = 1020mm
  • Weight: 400Kg
  • Hydraulic oil and the electrical connection are the charge of the client
    The capacity of the machine depends of the form, the humidity and the density of the chips.

ER44T

  • Briquette Ø70mm
  • Briquetting capacity between 30 and 60Kg/h for aluminum and between 60 and 80Kg/h for steel
  • Briquetting pressure of 230 bar so 1140Kg/cm²
  • Engine power 4KW
  • Hydraulic tank from 130L to 250L
  • Machine dimension:
    – l = 1700mm
    – L = 1300mm
    – H = 1400mm
  • Weight: 900Kg
  • Hydraulic oil and the electrical connection are the charge of the client

ER-202                        ER44T

Briquette Eco Series Features/Options Chart:
